头文件显示图形。h包含 bar3d（） 函数，用于绘制二维矩形填充条。绘制钢筋需要钢筋左上角和右下角的坐标。 语法：

null

void bar3d(int left, int top, int right,
    int bottom, int depth, int topflag);

where,
left specifies the X-coordinate of top left corner,
top specifies the Y-coordinate of top left corner,
right specifies the X-coordinate of right bottom corner,
bottom specifies the Y-coordinate of right bottom corner,
depth specifies the depth of bar in pixels,
topflag determines whether a 3 dimensional top is put on
the bar or not ( if it is non-zero then it is put otherwise not ).

例子：

Input : left = 150, top = 250,
        right = 190, bottom = 350,
        depth = 20, topflag = 1

        left = 220, top = 150,
        right = 260, bottom = 350,
        depth = 20, topflag = 0

        left = 290, top = 200,
        right = 330, bottom = 350,
        depth = 20, topflag = 1
Output :

下面是bar3d（）函数的实现：

                     // C Implementation for bar3d() function
                     #include <graphics.h>

                     // driver code
                     int                               main()
                     {
                                         // gm is Graphics mode which is
                                         // a computer display mode that
                                         // generates image using pixels.
                                         // DETECT is a macro defined in
                                         // "graphics.h" header file
                                         int                               gd = DETECT, gm;

                                         // initgraph initializes the
                                         // graphics system by loading a
                                         // graphics driver from disk
                                         initgraph(&gd, &gm,                               ""                               );

                                         // location of sides
                                         int                               left, top, right, bottom;

                                         // depth of the bar
                                         int                               depth;

                                         // top flag denotes top line.
                                         int                               topflag;

                                         // left, top, right, bottom,
                                         // depth, topflag location's
                                         bar3d(left = 150, top = 250,
                                         right = 190, bottom = 350,
                                         depth = 20, topflag = 1);

                                         bar3d(left = 220, top = 150,
                                         right = 260, bottom = 350,
                                         depth = 20, topflag = 0);

                                         bar3d(left = 290, top = 200,
                                         right = 330, bottom = 350,
                                         depth = 20, topflag = 1);

                                         // y axis line
                                         line(100, 50, 100, 350);

                                         // x axis line
                                         line(100, 350, 400, 350);

                                         getch();

                                         // closegraph function closes the
                                         // graphics mode and deallocates
                                         // all memory allocated by
                                         // graphics system .
                                         closegraph();

                                         return                               0;
                     }

输出：
